• Description
     55810-63J00
     HR1023
     Brake Pad Set
     SET

    Front Axle
    Brake System : AKB
    Width : 108.6 mm
    Height : 45.3 mm
    Thickness : 14.5 mm

Brake Pad Set:55810-63J00
Model Engine Chassis Type CYL year
CHANGAN (CHANA) CX20 Hatchback  0/10 - 2/12
SUZUKI SWIFT III (SG)  8/05 - /
SUZUKI SWIFT IV (FZ, NZ)  1/12 - /
SUZUKI (CHANGAN) SWIFT (EZ, MZ)  2/07 - /

Application

SUZUKI Swift (Latin America) 2007-2010


  • Recommends every 5,000 km check Brake System
    ensure the normal operation of the braking system
  • Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
  • Rear brakes is recommended to replace within 5-7 km
  • Replace the Disc brake when follow situation happen:
  • 1.Sensor alarm;
  • 2.Friction materials thickness less than 3mm;
  • 3.Friction materials becomes contaminated with brake fluid;
  • 4.Uneven wear within a set;
  • Replace the brake rote when follow situation happen:
  • 1.Vibrate when braking;
  • 2.Car vehicle performance more than 60000Km and braking unstable;
  • 3.Disc brake thickness wear more than 2mm;
