• Description
     04491-87613
     HR1016
     Brake Pad Set
     SET

    Front Axle
    Brake System : AKB
    Width : 127.7 mm
    Height : 52.2 mm
    Thickness : 14 mm

Brake Pad Set:04491-87613
Model Engine Chassis Type CYL year
DAIHATSU FEROZA Hard Top (F300)  0/88 - 2/99
DAIHATSU FEROZA Soft Top (F300)  0/88 - 2/99
DAIHATSU ROCKY Hard Top (F7, F8)  2/85 - 2/98
DAIHATSU ROCKY Soft Top (F7, F8)  2/85 - 2/98
DAIHATSU TAFT  8/78 - 8/82
DAIHATSU WILDCAT/ROCKY (F70)  2/85 - 3/87
DAIHATSU WILDCAT/ROCKY (F75)  2/85 - 3/87
ISUZU   6/85 - 2/88

Application

MAZDA B2200 Diesel 1982-1983


  • Recommends every 5,000 km check Brake System
    ensure the normal operation of the braking system
  • Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
  • Rear brakes is recommended to replace within 5-7 km
  • Replace the Disc brake when follow situation happen:
  • 1.Sensor alarm;
  • 2.Friction materials thickness less than 3mm;
  • 3.Friction materials becomes contaminated with brake fluid;
  • 4.Uneven wear within a set;
  • Replace the brake rote when follow situation happen:
  • 1.Vibrate when braking;
  • 2.Car vehicle performance more than 60000Km and braking unstable;
  • 3.Disc brake thickness wear more than 2mm;
