     04495-87204-000
     HRK0024
     Brake Shoe Set
     SET

    Rear Axle
    Diameter : 165 mm
    Width : 28 mm

Brake Shoe Set:04495-87204-000
Model Engine Chassis Type CYL year
DAIHATSU CUORE III (L201)  0/90 - 2/94
DAIHATSU CUORE IV (L501)  1/96 - 0/98
DAIHATSU CUORE V (L7_)  0/98 - 5/03
DAIHATSU CUORE VI (L251, L250_, L260_)  5/03 - /
DAIHATSU MOVE (L9_)  0/98 - 9/02

Application

DAIHATSU CUORE L70S 550 89' 3-90' 2
DAIHATSU CUORE L70S 550 89' 3-90' 2
DAIHATSU CUORE L70S 550 89' 3-90' 2
DAIHATSU MIRA L70V 550 F 85' 8-89' 3
DAIHATSU MIRA L200S 660 F 90' 3-95' 1
DAIHATSU MIRA L70V 550 F 85' 8-89' 3
DAIHATSU MIRA L500 660 TS,TX,TG,TA,TB 94' 8-98' 8
DAIHATSU MIRA L200S 660 TRXX 90' 3-95' 1
DAIHATSU MIRA L220S 660 F 90' 4-95' 1
DAIHATSU MIRA L220S 660 F 92' 7-95' 1
DAIHATSU MIRA L200V 660 F 90' 3-95' 1
DAIHATSU MIRA L200V 660 F 90' 3-95' 1
DAIHATSU MIRA L200V 660 F 90' 3-95' 1
DAIHATSU MIRA L502 660 TV/R 94' 8-98' 8
DAIHATSU MOVE L910S 660 4WD(Z4) 98' 10-
DAIHATSU MOVE L910S 660 4WD(CL) 98' 10-
DAIHATSU MOVE L900S 660 98' 10-
DAIHATSU LEEZA L100V 550 F 86' 11-89' 1
DAIHATSU LEEZA L100V 550 F 86' 11-90' 7
DAIHATSU LEEZA L111S 660 F 90' 8-92' 7
DAIHATSU LEEZA L111S 660 F 90' 8-92' 7
DAIHATSU LEEZA SPIDER L111SK 660 91' 11-92' 7
DAIHATSU OPTI L800S 660 ABS 00' 3-01' 9
DAIHATSU OPTI L800S 660 CL ABS 98' 11-00' 3
DAIHATSU OPTI L800S 660 CX ABS 98' 11-02' 8
DAIHATSU OPTI L810S 660 4WD ABS 98' 11-02' 8


  • Recommends every 5,000 km check Brake System
    ensure the normal operation of the braking system
  • Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
  • Rear brakes is recommended to replace within 5-7 km
  • Replace the Disc brake when follow situation happen:
  • 1.Sensor alarm;
  • 2.Friction materials thickness less than 3mm;
  • 3.Friction materials becomes contaminated with brake fluid;
  • 4.Uneven wear within a set;
  • Replace the brake rote when follow situation happen:
  • 1.Vibrate when braking;
  • 2.Car vehicle performance more than 60000Km and braking unstable;
  • 3.Disc brake thickness wear more than 2mm;
