• Description
     001 420 01 20
     HR1092- 1
     Brake Pad Set
     SET

    Rear Axle
    Brake System : ATE
    Width : 61.7 mm
    Height : 54.3 mm
    Thickness : 13.5 mm

Brake Pad Set:001 420 01 20
Model Engine Chassis Type CYL year
MERCEDES BENZ 190 (W201)  9/86 - 8/91

Application

MERCEDES-BENZ 190D 1984
MERCEDES-BENZ 190D 2.5L 1984
MERCEDES-BENZ 190E 1984
MERCEDES-BENZ 190E 2.3L 1984


  • Recommends every 5,000 km check Brake System
    ensure the normal operation of the braking system
  • Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
  • Rear brakes is recommended to replace within 5-7 km
  • Replace the Disc brake when follow situation happen:
  • 1.Sensor alarm;
  • 2.Friction materials thickness less than 3mm;
  • 3.Friction materials becomes contaminated with brake fluid;
  • 4.Uneven wear within a set;
  • Replace the brake rote when follow situation happen:
  • 1.Vibrate when braking;
  • 2.Car vehicle performance more than 60000Km and braking unstable;
  • 3.Disc brake thickness wear more than 2mm;
